25G SR SFP28 850nm 100m DOM Duplex LC MMF Optical Transceiver Module
- Max. Power Consumption 1W
- Tested in Targeted Switches for Superior Performance, Quality, and Reliability
- Hot Pluggable SFP+ MSA Compliant
- WD BOX - Support Real-time Configuration
- Digital Optical Monitoring Capability for Strong Diagnostic Capabilities
- Optical Interoperability with 10GBASE XENPAK, X2, and XFP Interfaces On the Same Link
- Class 1 FDA Laser Safety and RoHS Compliant
- IEEE 802.3ae Compliant
Model | Rate | Wavelength | Transmission Distance | Output Opt. Pwr. | Rx. Sensitivity | Laser | Interface |
FYPP-8596-M3BD | 10Gb/s | 850nm | 300M | -6~-1dBm | ≤-10dBm | VCSEL | LC/SC |
FYPP-1396-02BD | 10Gb/s | 1310nm | 2KM | -6~-0.5dBm | ≤-14.4dBm | FP | LC/SC |
FYPP-1396-10BD | 10Gb/s | 1310nm | 10KM | -6~-0.5dBm | ≤-14.4dBm | DFP | LC/SC |
FYPP-1596-40BD | 10Gb/s | 1550nm | 40KM | -1~3dBm | ≤-16dBm | EML | LC/SC |
FYPP-1596-80BD | 10Gb/s | 1550nm | 80KM | -1~4dBm | ≤-23dBm | EML | LC/SC |
FYPPC-**96-10BD | 10Gb/s | 1270nm~1610nm | 10KM | -6~-1dBm | ≤-15dBm | DFP | LC/SC |
FYPPC-**96-40BD | 10Gb/s | 1470nm~1610nm | 40KM | -1~3dBm | ≤-16dBm | EML | LC/SC |
FYPPC-**96-80BD | 10Gb/s | 1470nm~1610nm | 80KM | -1~4dBm | ≤-23dBm | EML | LC/SC |
FYPPD-**96-40BD | 10Gb/s | C17~C61 | 40KM | -1~3dBm | ≤-16dBm | EML | LC/SC |
FYPPD-**96-80BD | 10Gb/s | C17~C61 | 80KM | -1~4dBm | ≤-23dBm | EML | LC/SC |
Remark: Above"**"refers to the corresponding wavelength.
For CWDM models, it refers to the wavelength 1270nm~1610nm.
For DWDM models, it refers to the wavelength C17(1563.86)~C61(1528.77nm).
10Gb/s SFP+BIDI Single Mode Optical Transceiver
Model | Rate | Wavelength | Transmission Distance | Output Opt. Pwr. | Rx. Sensitivity | Laser | Interface |
FYPPB-2396-10BD | 10Gb/s | Tx1270/Rx1330nm | 10KM | -6~-0.5dBm | ≤-14.4dBm | DFP | LC |
FYPPB-3296-10BD | 10Gb/s | Tx1330/Rx1270nm | 10KM | -6~-0.5dBm | ≤-14.4dBm | DFP | LC |
FYPPB-2396-40BD | 10Gb/s | Tx1270/Rx1330nm | 40KM | -1~3dBm | ≤-16dBm | DFP | LC |
FYPPB-3296-40BD | 10Gb/s | Tx1330/Rx1270nm | 40KM | -1~3dBm | ≤-16dBm | DFP | LC |
FYPPB-2396-60BD | 10Gb/s | Tx1270/Rx1330nm | 60KM | 0~5dBm | ≤-20dBm | DFP | LC |
FYPPB-3296-60BD | 10Gb/s | Tx1330/Rx1270nm | 60KM | 0~5dBm | ≤-20dBm | DFP | LC |
FYPPB-4596-80BD | 10Gb/s | Tx1490/Rx1550nm | 80KM | -1~4dBm | ≤-23dBm | EML | LC |
FYPPB-5496-80BD | 10Gb/s | Tx1550/Rx1490nm | 80KM | -1~4dBm | ≤-23dBm | EML | LC |
