24x10GE SFP+ 6x40/100GE QSFP28 S6730-H24X6C Switches
Proporcionar gestión de red granular
Redes Ethernet flexibles
Pila inteligente (iStack)
Sincronización del reloj
Gestión basada en la nube
Características de VXLAN
O&M inteligente
Actualización inteligente
Seguridad colaborativa basada en big data
Sistema de programabilidad abierta (OPS）
CloudEngine S6730-H Series 10 GE Switches
CloudEngine S6730-H Series 10 GE Switches deliver 10 GE downlink and 100 GE uplink connectivity for enterprise campuses, carriers, higher education institutions, and governments, integrating native Wireless Local Area Network (WLAN) Access Controller (AC) capabilities, to support up to 1024 WLAN Access Points (APs).
The series enables the convergence of wired and wireless networks — greatly simplifying operations — offering free mobility to deliver a consistent user experience and Virtual Extensible Local Area Network (VXLAN)-based virtualization, creating a multi-purpose network. With built-in security probes, CloudEngine S6730-H supports abnormal traffic detection, Encrypted Communications Analytics (ECA), and network-wide threat deception.
| Product Model | CloudEngine S6730-H48X6C | CloudEngine S6730-H24X6C |
Fixed ports | 48 x 10 Gig SFP+, 6 x 40/100 Gig QSFP28 | 24 x 10 Gig SFP+, 6 x 40/100 Gig QSFP28 |
Dimensions (H x W x D) | 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.4 in. x 16.5 in.) | 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.4 in. x 16.5 in.) |
Chassis height(U) | 1U | 1U |
Rated voltage range | ⚫ AC input: 100 V AC to 240 V AC, 50/60 Hz ⚫ High-Voltage DC input: 240 V DC ⚫ DC input: -48 V DC to -60 V DC | |
Maximum voltage range | ⚫ AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz ⚫ High-Voltage DC input: 190 V DC to 290 V DC ⚫ DC input: -38.4 V DC to -72 V DC | |
Maximum input current | ⚫ AC 600W：8A ⚫ DC 1000W：30A | |
Typical power consumption | 165 W | 149 W |
Maximum power consumption | 291 W | 254 W |
Operating temperature | -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) | |
Storage temperature | -40°C to +70°C (-40°F to +158°F) | |
Operating altitude | 0-5000 m (0-16404 ft.) | |
Noise (sound pressure at normal temperature) | < 65 dB(A) | |
Power supply surge protection | ⚫ Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode ⚫ Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode | |
Power supply type | ⚫ 600 W AC Power Module ⚫ 1000 W DC Power Module | |
Relative humidity | 5% to 95%, noncondensing | |
Fans | 4, Fan modules are pluggable | |
Heat dissipation | Heat dissipation with fan, intelligent fan speed adjustment | |
