1M Multimode Trunk Cable 8/12/24f LC OM3/OM4 MPO MTP Fiber Optical Patch Cord

MPO
Fiber optic patch cord is used for linking the equipment and components in fiber optic network, is comprised of a polymer outer body and inner assembly fitted with a precision alignment mechanism. The combination of a ceramic/phosphor bronze alignment sleeves and precision molded polymer housing provides consistent long-term mechanical and optical performance.
Quantity
Contact Now
add to cart
Features
MPO connector complied with IEC-61754-7
A quick-to-deploy
Scalable solution
High compatibility,flexibility&system performance
Lower installation cost
Applications
SAN (Storage area Network)data center LAN
LAN/SAN switch equipment distribution area(EDA)
Emerging 40G and 100G protocol
MPO Connector
Standard SM MT Ferrule
Low Loss SM MT Ferrule
Standard MM MT Ferrule
Low Loss MM MT Ferrule
Polish
APC
PC
APC
PC
PC
PC
Insertion Loss(dB)
Typical
0.50
0.50
0.30
0.30
0.50
0.30
Maximun
0.70
0.70
0.50
 0.50
0.70
0.50
Return Loss（dB）
60
45
60
45
20
20
Exchangeability(dB）
≤0.3
Durability（dB）
≤0.2dB (500 Matings,per EIA-455-21A)
Tensile Strength（dB）
≤0.3dB (Max 66N)
Operating temperature（℃）
-20~+60
Storage temperature（℃）
-40~+80
MT Ferrule(Male&FEmale)
