CFP2 100G LR4 1310nm 10km DOM LC SMF Transceiver Module

100G CFP2 LR4 optical Transceiver integrates receiver and transmitter path on onemodule. In the transmit side, four lanes of serial data streams are recovered, retimed, and passed to four laser drivers. The laser drivers control four EMLs (Electric-absorption Modulated Lasers) with center wavelength of 1296 nm, 1300nm, 1305nm and 1309 nm. The optical signals are multiplexed to a single –mode fiber through an industry standard LC connector. In the receive side, the four lanes of optical data streams are optically de-multiplexed by the integrated optical de-multiplexer. Each data stream is recovered by a PIN photo-detector and trans-impedance amplifier, retimed.

This module features a hot-pluggable electrical interface, low power consumption and MDIO management interface. The module provides an aggregated signaling rate from 103.125 Gbps to 111.81Gbps. It is compliant with IEEE 802.3ba 100GBASE-LR4 and ITU-T G.959.1 4I1-9D1F , and OIF2010.404.08 CEI-28G-VSR electrical specifications. The MDIO management interface complies with IEEE802.3ba standard. The transceiver complies with CFP MSA CFP2 Hardware Specification Rev. 1.0,CFP MSA Management Interface Specification, and OIF CEI-28G-VSR standards.
