25G SFP28 Passive Direct Attach Copper Twinax Cable
25G DAC
25G SFP28 Passive Direct Attach Copper Twinax Cable is designed for use in 25GBASE Ethernet. This cable is compliant with IEEE P802.3by Ethernet standard and SFP28 MSA Compliant.
Each SFP28 connector comprises an EEPROM providing product information which can be read by the host system. With these features, this easy to install, high speed, cost-effective direct attach copper twinax Cable is suitable for short-distance connectivity within a rack or between adjacent racks in data centers.
Each SFP28 connector comprises an EEPROM providing product information which can be read by the host system. With these features, this easy to install, high speed, cost-effective direct attach copper twinax Cable is suitable for short-distance connectivity within a rack or between adjacent racks in data centers.
Quantity
Product Highlights
● Max. Power Consumption 0.5W
● Tested in Targeted Switches for Superior Performance, Quality, and Reliability
● Minimum Bend Radius 25mm for Flexible Routing
● Simplifies the Patching and Offers a Cost-effective Way for Short Links
● Support Real-time Configuration
● Hot Pluggable SFP28 MSA Compliant
● Low Insertion Loss and Ultra-low Crosstalk for Improved Performance
● RoHS Compliant
| Wodata SeriesDirect Attach Copper Twinax Cable | |||||||||
| Connector Type | Rate | Media | Power Supply | Wire AWG | Cable Length | Jacket Material | Cable Type | Temperature | Power Consumption |
| SFP+ to SFP+ | 10G | Copper | 3.3V | 30AWG | 1m (3ft) | PVC (OFNR) | Passive Twinax | 0 to 70°C | ≤0.1W |
| SFP28 to SFP28 | 25G | Copper | 3.3V | 30AWG | 1m (3ft) | PVC (OFNR) | Passive Twinax | 0 to 70°C | ≤0.5W |
| QSFP+ to QSFP+ | 40G | Copper | 3.3V | 30AWG | 1m (3ft) | PVC (OFNR) | Passive Twinax | 0 to 70°C | ≤0.5W |
| QSFP+ to 4SFP+ | 40G | Copper | 3.3V | 30AWG | 1m (3ft) | PVC (OFNR) | Passive Twinax | 0 to 70°C | ≤0.5W |
| QSFP28 to QSFP28 | 100G | Copper | 3.3V | 30AWG | 1m (3ft) | PVC (OFNR) | Passive Twinax | 0 to 70°C | ≤0.5W |
| QSFP28 to 4*SFP28 | 100G | Copper | 3.3V | 30AWG | 1m (3ft) | PVC (OFNR) | Passive Twinax | 0 to 70°C | ≤0.5W |
| QSFP56 to QSFP56 | 200G | Copper | 3.3V | 30AWG | 1m (3ft) | PVC (OFNR) | Passive Twinax | 0 to 70°C | ≤0.1W |
QSFP-DD to QSFP-DD | 400G | Copper | 3.3V | 30AWG | 1m (3ft) | PVC (OFNR) | Passive Twinax | 0 to 70°C | ≤0.1W |
Qualified through a rigorous process with advanced equipments to ensure you get the high quality and reliable optics.
