100G QSFP28 Active Optical Cable
100G AOC
QSFP28 Active Optical Cables are direct-attach fiber assemblies with QSFP28 connectors and operate over Multi-Mode Fiber (MMF). This AOC is compliant with QSFP28 MSA and RoHS-6 standards. It provides a cost-efficient solution as compared to using discrete optical transceivers and optical patch cables and is suitable for 100Gbps connections within racks and across adjacent racks.
Quantity
Product Highlights
● Max. Power Consumption 3.5W
● Tested in Targeted Switches for Superior Performance, Quality, and Reliability
● Minimum Bend Radius 7.5mm for Flexible Routing
● Simplifies the Patching and Offers a Cost-effective Way for Short Links
● Support Real-time Configuration
● Hot Pluggable QSFP28 MSA Compliant
● Class 1 FDA Laser Safety and RoHS Compliant
| Wodata Series Active Optical Cables | |||||||||
| Connector Type | Rate | Cable Type | Cable Length | Minimum Bend Radius | Power Consumption | ||||
| SFP+ to SFP+ | 10G | 850nm | **M(＜300M) | VCSEL | PIN | Optical Cable | 1m (3.28ft) | 7.5mm | <1W |
| SFP28 to SFP28 | 25G | 850nm | **M(＜100M) | VCSEL | PIN | Optical Cable | 1m (3.28ft) | 7.5mm | <1W |
| QSFP+ to QSFP+ | 40G | 850nm | **M(＜300M) | VCSEL | PIN | Optical Cable | 1m (3.28ft) | 7.5mm | <1W |
| QSFP+ to 4SFP+ | 40G | 850nm | **M(＜300M) | VCSEL | PIN | Optical Cable | 1m (3.28ft) | 7.5mm | <1W |
| QSFP28 to QSFP28 | 100G | 850nm | **M(＜100M) | VCSEL | PIN | Optical Cable | 1m (3.28ft) | 7.5mm | <1W |
| QSFP28 to 4*SFP28 | 100G | 850nm | **M(＜100M) | VCSEL | PIN | Optical Cable | 1m (3.28ft) | 7.5mm | <1W |
| QSFP56 to QSFP56 | 200G | 850nm | **M(＜100M) | VCSEL | PIN | Optical Cable | 1m (3.28ft) | 7.5mm | <1W |
Qualified through a rigorous process with advanced equipments to ensure you get the high quality and reliable optics.
