1000BASE-T SFP Copper RJ-45 100m Transceiver Module
1000BASE-T Copper RJ-45
SFP transceiver supports up to 100m link lengths over a copper connection via a RJ-45 connector. Each SFP transceiver module is individually tested to be used on a series of Cisco switches, routers, servers, network interface card (NICs) etc.
Featuring low power consumption, the hot swappable 1G SFP transceiver is ideal for enterprise networking for LAN applications and different other networking places using copper connections.
Featuring low power consumption, the hot swappable 1G SFP transceiver is ideal for enterprise networking for LAN applications and different other networking places using copper connections.
Quantity
Product Highlights
● Hot Pluggable SFP MSA Compliant to Maximize Uptime and Simplify Maintenance
● Max. Power Consumption 1.2W Allowing for Prolonged Service Life
● Commercial Temperature Range 0 to 70°C (32 to 158°F)
● Support Real-time Configuration
● Compliant to IEEE Std 802.3 and 802.3ab Gigabit Ethernet
● Tested in Targeted Switches for Superior Performance, Quality, and Reliability
| Form Factor | SFP | Max Data Rate | 1000Mbps |
| Media | Cat 5e/6/6a | Cable Distance | 100m |
| Connector | RJ-45 | Rx LOS | NO |
| Power Consumption | ≤1.2W | DDM/DOM | Not Supported |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) | Protocols | IEEE Std 802.3 and 802.3ab, SFP MSA Compliant |
| Bit Error Ratio (BER) | 1E-12 | MTBF | 217,330 Hours |
| EMC | Supported | Warranty | 5 Years |
Comprehensive Testing Increases Reliability
Qualified through a rigorous process with advanced equipments to ensure you get the high quality and reliable optics.
