GPON OLT SFP Class C++ 20km Optical Transceiver Module
GPON C++
The GPON OLT SFP transceiver provides up to 2.5G-TX/1.25G-RX up to 20km over single-mode fiber (SMF) using a wavelength of 1490nm-TX/1310nm-RX via an SC connector. It can operate at temperatures between -40°C and 85°C. Digital optical monitoring (DOM) support is also present to allow access to real-time operating parameters. It is fully compliant with ITU-T G.984.2 and RoHS standards and is ideal for GPON system and FTTx applications.
Quantity
Product Highlights
● Low-cost DFB Laser for Reliable Network
● -40 to 85°C I-Temp Range and TO Hermetic Package for Harsh Outdoor Environments
● Single Fiber Bi-directional Data Links with Asymmetric 2.488Gbps Tx and 1.244Gbps Rx
● EMI Shielding FCC Class C++ Compliant
● ITU-T G.984.2 and RoHS Compliant
| GPON OLT SFP | 2.5G-TX/1.25G-RX | ||
| 1490nm-TX/1310nm-RX | 20km | ||
| SC | Cable Type | SMF | |
| DFB | APD | ||
4.5~8 dBm | <-33dBm | ||
| 37.5dB | >-12dBm | ||
＜1.5W | >8.2dB | ||
Industrial Temperature Range | -40 to 85°C (-40 to 185°F) | Protocols | ITU-T G.984.2, RoHS |
Qualified through a rigorous process with advanced equipments to ensure you get the high quality and reliable optics.
